Upgrading Singapore's Broadcast Infrastructure — A Full AV Connectivity Deployment
Verified outcomes from energy saving, industrial IIoT, digital twin, and broadcast infrastructure deployments across Singapore.
Client Context
A leading Singapore free-to-air broadcast network undertook a major studio and MCR (Master Control Room) upgrade to transition from SD/HD legacy infrastructure to a fully 4K-capable, IP-ready broadcast facility. The project required the complete replacement of all signal routing, audio patching, video transmission, and network distribution hardware across five production studios, the MCR, and two OB truck integration bays
Challenge
The upgrade needed to maintain continuous broadcast operations — no signal path could go dark during a scheduled programme. All new hardware required full compatibility with existing SMPTE 2110 IP video infrastructure being installed by the system integrator. Equipment needed to be sourced from authorised distributors with full manufacturer certification, warranty, and traceability — a broadcast compliance requirement for major studio facilities.
LHS Electronics Solution
balanced audio throughout all five studios and MCR
IP65 ruggedised locking RJ45 for SMPTE 2110 network patch positions and OB truck integration bays
locking speaker connectors for studio monitor amplifier systems
12 GHz rated BNC connectors for 4K/8K SDI routing and patch bay positions
bantam patchbays TT bantam patching for analogue audio routing in the MCR
SDI video patching in the MCR with 75Ω impedance maintained throughout
SDI camera chains and monitoring distribution
Outcome
- Complete transition to 4K-capable signal routing with zero broadcast interruption
- Full manufacturer certification and traceability documentation supplied
- All equipment specified to SMPTE 2110 and AES67 compatibility requirements
- Ongoing supply partnership for consumables and spare connector inventory
Technology Brands
